Description |
Value |
| ABS/Non-ABS |
Y |
| Bearing Type |
Ball |
| Bolt Circle Diameter B |
4.75 |
| Bolt Circle Diameter B |
120.65 |
| Bolt Circle Diameter H |
100.603 |
| Bolt Circle Diameter H |
3.961 |
| Bolt Quantity Size I |
M10x1.5 |
| Bolt Quantity Size I |
(4) |
| Brake Pilot Dia E |
70.6 |
| Brake Pilot Dia E |
2.77952755905512 |
| Driven - Non Driven |
N |
| Flange Diameter A |
5.787 |
| Flange Diameter A |
147 |
| Flange Offset F |
68.72 |
| Flange Offset F |
2.70551181102362 |
| Flange Shape J |
Rectangle |
| Gen Type |
3 |
| Hub Pilot Dia G |
2.82362204724409 |
| Hub Pilot Dia G |
71.72 |
| Lug Bolts (Y/N) |
Y |
| Pass |
Y |
| Roll Form |
N |
| Spline Quantity |
- |
| Stud Quantity Size |
M12x1.5 |
| Stud Quantity Size |
(5) |
| Tone Ring / # Teeth |
- |
| Tone Ring / Sensor / Encoder |
S |
| Tone Ring Dia. |
- |
